CIFA Mix 120 B:

  • production of vibrated concrete: 120 cm/h
  • mixer net concrete output: 3 cm/cycle
  • number of aggregates compartments: up to 5
  • aggregates storage capacity: up to 220 cm
  • number of cement silos: up to 6
  • aggregates loading system: ramp
  • mixer feeding system: skip hoist or inclined belt conveyor
CIFAMIX TECHNICAL DATA 100 120
PLANT CONCRETE OUTPUT (m3/h) 100 120
MODEL OF MIXER DNA 2.25 DNA 3.0
TYPE OF MIXER helicoidal twin shaft helicoidal twin shaft
MIXER CAPACITY (l) 3350/2250 4500/3000
MIXER CONCRETE OUTPUT (m3/cycle) 2.25 3.0
AGGREGATE BINS (n) 4 / 5 / 6 4 / 5 / 6
AGGREGATE STORAGE CAPACITY (m3) 104 / 130 / 156 104 / 130 / 156
CEMENTS (n) up to 6 up to 6
MIXER FEEDING SYSTEM skip hoist or inclined belt skip hoist or inclined belt
AGGREGATE LOADING SYSTEM inclined belt or ramp inclined belt or ramp



CIFA Move 60:

Concrete batching plant equipped with CIFA horizontal twin shaft mixer, consisting of a single module that can be transported by semi-trailer, easy and quick to install

  • production of vibrated concrete: 60 cm/h
  • mixer net concrete output: 1.5 cm/cycle
  • number of aggregates compartments: 4
  • aggregates storage capacity: 45 cm
  • number of cement silos: up to 4
  • aggregates loading system: ramps or inclined belt
  • mixer feeding system: skip
TECHNICAL DATA CIFAMOOVE 30 CIFAMOBILE 50 CIFAMOOVE 60 CIFAMOOVE 75 CIFAMOOVE 90 CIFAMOOVE 100
PLANT CONCRETE OUTPUT (m3/h) 30 50 60 75 90 95
MIXER MODEL PNA 0.5 DNA 1.0 DNA 1.5 DNA 1.5 DNA 2.0 DNA 2.25
MIXER TYPE planetary helicoidal twin shaft helicoidal twin shaft helicoidal twin shaft helicoidal twin shaft helicoidal twin shaft
MIXER CAPACITY (l) 750/500 1500/1000 2250/1500 2250/1500 3000/2000 3370/2250
MIXER CONCRETE OUTPUT (m3/cycle) 0.5 1.0 1.5 1.5 2.0 2.25
AGGREGATE BINS (n) 4 4 4 4 / 5 / 6 4 / 5 / 6 4
AGGREGATE STORAGE (m3) 32 40 45 104 / 130 / 156 104 / 130 / 156 104 / 130 / 156
CEMENTS (n) up to 2 up to 4 up to 4 up to 4 up to 4 up to 4
AGGREGATE WEIGHING DOSING belt belt skip belt belt belt
CEMENT AND WATER DOSING by weight by weight by weight by weight by weight by weight
AGGREGATE LOADING SYSTEM 2 ramps 2 ramps or belt conveyor 2 ramps or belt conveyor 1 ramp 1 ramp 1 ramp
